Using 5G leaky cable laser cutting machine to help 5G layout

The large-scale layout of 5G, as early as the first half of 2019, the three major operators have begun to deploy 5G on a large scale, and several 5G mobile phones have been launched.
To achieve full coverage of 5G, it is essential to lay out leaky cables, which are also called leaky coaxial cables. In the large layout of 5G coverage, leaky cables are as important and ubiquitous as blood vessels. The main function of leaky cables is signal transmission, and they can also function as antennas. The key point here is that by controlling the opening of the conductor, the controlled electromagnetic wave energy can be evenly radiated and received along the line, achieving coverage of the blind area of the electromagnetic field, so as to achieve the purpose of smooth mobile communication-"opening".

For the processing of this "opening", it is necessary to cut off the outer layer of aluminum every one or several meters to expose the inner layer of PET. Most of the common traditional processing methods belong to the mechanical contact type of board separation process, and the disadvantages are also obvious: slow efficiency, stress, easy to produce burrs, dust, low precision, and most importantly, the cost is not low. Laser cutting technology has gradually been used abroad, while most of the domestic ones are still using the original copper cutting.
As a non-contact processing tool, 5G leaky cable laser cutting equipment can apply high-intensity light energy (650mW/mm2) on a very small focus (100-500渭m). Such high energy can be used to perform laser cutting, drilling, marking, welding, scribing and other processing on materials.
The advantages of using laser to cut 5G leaky cables are also obvious:
1. Laser cutting does not require consumables, which is both environmentally friendly and cost-saving;
2. Laser cutting of 5G leaky cables uses a high-performance fiber laser light source with good beam quality, high cutting accuracy and better results;
3. Laser cutting5G leaky cables are non-contact processing, which effectively avoids damage and deformation of the processed materials and does not cause any damage to the underlying PET.
